AllPoints ALLP26363 10 1/2" x 17" Bottom Grate – Replaces Star Mfg 2F-Z3077

Introduction:
The AllPoints ALLP26363 Bottom Grate is a durable cast iron replacement grate designed for select Star Mfg and Stero broilers. Measuring approximately 17-1/16" x 10-1/2", this heavy-duty bottom grate ensures even heat distribution and reliable performance in commercial kitchen environments.

Detailed Description:
Constructed from high-quality cast iron, this bottom grate is built to withstand high cooking temperatures and continuous commercial use. It features 4 cross bars and 11 ribs, providing optimal support and heat retention for consistent grilling results. Designed as a direct replacement for Star Mfg part number 2F-Z3077 (also referenced as Z3077) and compatible Stero part numbers STA2F-Z3077 and STAZ3077, this grate restores your broiler’s performance and extends equipment life.

This unit measures approximately 17-1/16" x 10-1/2". If a 17-1/4" x 10-1/2" grate is required, use AllPoints #24-1218 instead. Please note that OEM configurations may now require quantity two of AllPoints #24-1157 to replace the single grate #24-1120 (17-1/16" x 21").

Compatible with various Star broiler models including 6000, 6100, 6024CBB-LP, 6024CBC, 6024CBD, 6024CBSB, 6024CBZ, 6024CBZ-LP, 6036CBB-LP, 6036CBC, 6036CBD, 6036CBSB, 6036CBZ, 6036CBZ-LP, 6048CBB-LP, 6048CBC, 6048CBD, 6048CBZ, 6048CBZ-LP, 6124RCBD, 6136RCBD, and 6148RCBD.

Product Details:

  • Manufacturer: AllPoints
  • AllPoints Part Number: 241157
  • Model: ALLP26363
  • Replaces Star Part Numbers: 2F-Z3077, Z3077
  • Replaces Stero Part Numbers: STA2F-Z3077, STAZ3077
  • Material: Cast Iron
  • Dimensions: 17-1/16" x 10-1/2"
  • Height: 0.29"
  • Length: 6.69"
  • Width: 4.13"
  • Construction: 4 cross bars, 11 ribs
  • Ship Weight: 31.59 lbs
  • Compatible Make: Star Mfg
  • Application: Bottom grate for commercial broilers
  • Note: Verify required size before ordering; alternate sizes and OEM configuration changes may apply.
Product Spec
  • Pack Size:

    EA
