Lang 124T – Electric Countertop Convection Oven with Factory-Mounted Clamshell Hood System

Introduction:
The Lang 124T is a heavy-duty commercial electric countertop convection oven engineered for high-performance cooking in professional foodservice environments. This unit is equipped with the CSE12AG Electric Clamshell Hood and CSE12AMG24 mounting system, providing enhanced cooking versatility and rapid heat response for griddle-style applications.

Detailed Description:
The 124T operates on 208V/240V, 60 Hz, 3-phase power, drawing 50.0 amps and delivering 12 kW of cooking power. The unit is field wired and field convertible to single-phase, offering installation flexibility for a variety of commercial kitchen electrical configurations.

This configuration includes the CSE12AG Electric Radiant Clamshell Hood, featuring an 11" W x 21.5" D cooking surface. The clamshell provides instant ON heating when lowered and automatically switches to standby mode when raised, improving energy efficiency and cook time consistency. It offers a 3-inch plate clearance and operates at 208V/60Hz, 1-phase, drawing 15.4 amps per line with 3.2 kW output. The system is cETLus and NSF certified and is factory mounted.

The CSE12AMG24 Frame and Mounting System is designed specifically for electric clamshell mounting to a 24" griddle configuration. This non-contact griddle system maintains a 3-inch clearance, ensuring proper radiant heat distribution without direct surface contact, supporting consistent cooking performance and durability.

Together, these integrated systems enhance production speed, improve energy management, and provide consistent top-side heating for proteins, sandwiches, and high-volume griddle applications in commercial kitchens.

Electrical Specifications:

• Main Unit Voltage: 208V/240V
• Frequency: 60 Hz
• Phase: 3-Phase (Field Convertible to 1-Phase)
• Main Power Output: 12 kW
• Main Amperage: 50.0 Amps
• Clamshell Voltage: 208V / 60Hz / 1-Phase
• Clamshell Output: 3.2 kW
• Clamshell Amperage: 15.4 Amps per Line
• Wiring: Field Wired

Product Details:

• Manufacturer: Lang
• Model Number: 124T
• Type: Countertop Convection Oven with Electric Clamshell Hood
• Clamshell Cooking Surface: 11" W x 21.5" D
• Plate Clearance: 3"
• Heating Type: Radiant, Instant-On When Lowered
• Mounting System: CSE12AMG24 Frame for 24" Griddle
• Certifications: cETLus, NSF
• Pack Size: 1 Unit
• Application: Ideal for high-volume sandwich production, proteins, griddle cooking, and commercial foodservice operations
